DCP TEST/ DYNAMIC CONE PENETROMETER

DCP TEST/ DYNAMIC CONE PENETROMETER For determination of field CBR value ( rapid quality control)

Consist of :
SO-151 Handle; stainless steel ( 1 pc) SO-152 Hammer; machined steel, Painted, 8 kg weight ( 1 pc) SO-153 Guide Rod ( 1 pc) Stainless steel, 16 mm dia drop height 575 mm SO-154 Anvil; machined steel, welded painted ( 1 pc) SO-155 Penetration Rod Stainless steel, 16 mm dia, 107 length ( 1pc) SO-156 Cone ( 3 pcs) Hardened tool steel cone tip, 60 deg. angle, 20 mm dia., stainless steel adaptor. SO-157 Penetration Scale ( 1 pc) Stainless steel, 16 mm dia, 100 cm scale. SO-158 Carrying Bag; water proof cloth ( 1 pc) GE-730 A Open End Wrench; vanadium steel 12/ 13, 14/ 15 ( 2 pcs) Dimension ( l x w x h) : 115 x 20 x 20 cm Gross Weight : 15 kg
